New inverter technologies offer installers the choice of central of distributed systems for PV arrays. Deciding which system is the most optimal to use isn’t always based on the size of a solar system, writes Alvaro Zanon.
A significant part of the risk management process associated with large-scale solar PV installations is ‘technical due diligence’, which seeks to define and minimise all technical risks associated with the project. Fred Martin and Nick Morley of TÜV Rheinland explore due diligence challenges for PV power plants in Japan.
More than ever, the global PV market provides attractive new investment opportunities, but the elements driving such rapid expansion also increase the risk of solar financial assets failing to meet long-term fiscal and performance goals. Boris Farnung, Björn Müller and Klaus Kiefer of Fraunhofer ISE, and Peter Bostock and John Sedgwick of VDE Americas explore major quality-assurance measures and the challenges today for achieving bankability of utility-scale PV plants.
A shift from free-abrasive/steel wire sawing to fixed-abrasive diamond wire sawing is expected to take place in the PV cell manufacturing industry, with 2018 being the anticipated pivotal point for market dominance. This shift is due to several key advantages of diamond wire sawing, such as higher throughput, less wire per wafer, no slurry and the possibility of kerf recycling. However, in order for diamond wire sawing to realize its promise as the next-generation workhorse for the slicing of silicon PV wafers, inherent fundamental challenges must be properly identified and successfully addressed by the PV industry. As a first step to increasing the current collective understanding of the critical needs/challenges of diamond wire sawing, the c-Si programme of the U.S. PVMC held a workshop on July 8th, 2014 in San Francisco, California. One of the key products of this workshop was an extensive list of short- and long-term challenges. This article expands on some of the most important challenges identified at the workshop through the collective discussions and dialogue among a variety of PV industry experts and stakeholders.
The manufacturers of silicon wafer solar cells are constantly looking into cost-effective ways to increase the efficiency of their solar cells. Most of these enhancements result from incremental improvements and can be achieved by optimizing existing processes. However, it is widely recognized that in order to further improve the silicon wafer solar cell efficiency, new solar cell architectures are required. This will in turn require new manufacturing processes, which will typically involve new production equipment and consumables. New consumables can play an important role in the applicability or success of a new process step; in this paper a specific focus will be on the precursors used for the deposition of surface passivation films, such as silicon nitride and aluminium oxide.
In edition 26 of Photovoltaics International the rebirth of PV manufacturing capacity expansions in 2014 was analysed; this covered announcements on a global basis from a wide range of companies and included thin film and dedicated solar cell and module assembly lines, as well as integrated cell and module assembly lines. Because of the current level of capacity expansion announcements, a roughly quarterly analysis of such plans will be undertaken during 2015.
Ion implantation offers significant process simplification potential for the fabrication of back-junction back-contact (BJBC) solar cells. First, the number of high-temperature steps can be reduced to one when applying a co-annealing process which includes an in situ growth of a silicon oxide passivation layer. Second, the implanted regions can be patterned in situ by utilizing shadow masks. ISFH's results from evaluating both aspects are reported in this paper. With fully ion-implanted, co-annealed and laser-structured small- area cells, efficiencies of up to 23.41% (20mm x 20mm designated area) have now been achieved. It is shown that the excellent recombination behaviour of 156mm x 156mm BJBC cells patterned in situ implies a potential for realizing efficiencies greater than 23%; however, back-end issues have so far limited the efficiency to 22.1% (full-area measurement). Ion implantation can also be utilized for the doping of BJBC cells with carrier-selective junctions based on polycrystalline silicon. The current status of ISFH's work in this direction is presented.
This paper presents the main features of imec’s n-PERT (passivated emitter rear totally diffused) cells, which have achieved independently confirmed efficiencies of 22%. A special focus is given to the selective front-surface field formation by laser doping, which – combined with imec’s front-plating sequence and the excellent rear-surface passivation by Al2O3 on the boron-diffused emitters – has enabled very high voltages (close to 685mV) to be realized on large-area n-type Cz material.
This paper reports on the status of large-area, 156mm, bifacial, n-type passivated emitter and rear totally diffused (n-PERT) solar cells, which feature full-area homogeneous doped regions on the front and rear sides. The fabrication process includes either two separate gas-phase diffusion processes with sacrificial diffusion barrier layers, or a sophisticated co-diffusion approach, in which a deposited stack of borosilicate glass (BSG) and silicon oxide acts as a dopant source during back-surface field (BSF) formation in a tube furnace. Thus, the co-diffusion approach reduces the number of required high-temperature processes to one, which significantly streamlines the process sequence. It is shown that by implementing two deposition phases during the BSF diffusion process, it is possible to separately control both the depth and the surface concentration of the BSF. The use of a tailored BSG source allows low recombination and specific contact resistance values on both the front and rear sides, resulting in peak conversion efficiencies of 19.9%. A discussion on the recombination at the emitter -metal interface completes the paper, and several paths to driving the conversion efficiency towards 22% are outlined.
In the last few years PV technology has seen continuous improvements, with significant enhancements at the cell and module levels. In addition to the requirement of high efficiency, the long-term reliability of PV modules leads to proposals for innovative module concepts and designs. Meyer Burger has developed a low-temperature wire-bonding technology, known as SmartWire Connection Technology (SWCT), with the aim of offering a cost-effective solution for high-efficiency solar cells while minimizing cell-to-module losses. The introduction of this interconnection design immediately brings new challenges, especially in the selection of an appropriate encapsulant, which must ensure a good processability as well as the required long-term module reliability. The compatibility of the most cost-effective types of encapsulant currently available on the market was analysed in the study reported in this paper. Thermoplastic polyolefin encapsulants with water absorption less than 0.1% and no (or few) cross-linking additives have proved to be the best option for long-lasting PV modules in a glass-glass (GG) configuration. The development of a laminator having a symmetrical structure (two heating plates without any vacuum membrane) has also opened the door to fast lamination processes with cycle times under eight minutes.
