Building-integrated photovoltaics or BIPV is one form of solar electricity that looks set to dominate the solar market in the coming years. The increase in BIPV installations is already evident in some European countries as governments begin to tweak their policies in order to provide a platform for this technology. The past few months have seen countries such as France and Italy make efforts to up the installation rate of this integrated form of solar, increasing the feed-in tariff (FiT) rate quite substantially for BIPV and lowering it for the more common installations such as roof and ground-mounted systems in order to increase the uptake. This BIPV-dedicated section will focus on the new policies implemented in France and Italy, concentrating on France’s policies as a blueprint for others. It will provide a focus on why governments are so keen to increase incentives in favour of BIPV and what the future implications of this market shift will be.
In most complex manufacturing environments, equipment failures dominate. These failures are commonly referred to as ‘fires’ because of the chaos and damage they inflict on factory operations. For example, a key piece of equipment fails, creating a blockage in the production line. One or more personnel are quickly dispatched to fix the problem. The situation is dire, threatening to slow daily product starts and slip output goals. Those working the problem know this failure is of the utmost importance and know if they can just get the machine at an acceptable level, the stress from management will be lifted. Logic leads these personnel to suspect a specific component, which is then replaced. This paper discusses the best method of ensuring that this ‘patching’ of problems does not become part of the regular maintenance routine.
Thin-film module production has proven itself as a forerunner in the race to drive down costs for photovoltaics. The type of semiconductor material used is the most differentiating factor for thin-film photovoltaics, playing the decisive role for determining which core processes are employed and what type of equipment is used. This explains why discussions related to thin-film costs and technologies usually focus on the semiconductor type. However, the effects of glass production, processing and handling are often underestimated: factors such as scaling, yield, unit cost and total cost of ownership of the equipment are defined by the glass-production side of the industry. This paper discusses the challenges faced in glass washing and handling in thin-film PV production.
As polysilicon producers perform expansions and upgrades to increase production and improve operations, plant safety remains critical. Companies should routinely review their safety policies and effectively plan their projects to ensure uninterrupted product supply and create a safe environment for employees and the communities in which they operate. Both the design and the execution of expansion and upgrades to projects are critical as companies strive for minimal down time so that productivity is not affected. Such hazards and scenarios that may hinder and delay start-up, specifically in relation to polysilicon plants, are highlighted in this paper. Furthermore, the paper outlines how best to avoid these situations, offering methods of execution to achieve the three key measures of success: safety, high purity and minimal downtime.
Upgraded metallurgical-grade (UMG) silicon is a lower cost and lower quality form of solar-grade silicon that is capable of producing solar cells at over 16% efficiency. This paper presents some of the economic advantages and technical concerns and solutions associated with producing silicon based PV from UMG, as well as preliminary solar cell results using this material. Results are based on a comparison of cells made in a turnkey line (Schmid Group) using alloy blends of 10%, 20%, 30% and 100% UMG, mixed with solar-grade Si before ingot growth. Detailed characterization was carried out on these finished cells according to lifetime, LBIC, diffusion length and luminescence imaging to determine correlations of performance with basic parameters. Requirements for material cost and cell performance necessary for UMG solar cells to be cost competitive are also presented.
Interconnection of inverters to the electrical grid is a key issue for the widespread integration of distributed energy resources, especially when the scenario surrounding international standards is so unclear. As a pre-normative research step, a round-robin test of two small-scale photovoltaic inverters was performed by nine DERlab laboratories during 2009. The test activity was focused on the verification of individual test procedures, common interpretation of standards and requirements, and determination of problems related to the equipment and facilities involved in conducting roundrobin.
An improved understanding of multicrystalline wafer quality can explain variations in cell performance across multicrystalline silicon blocks. Infrared scanning can detect precipitates in a silicon block, while photoluminescence combined with defect etching can reveal needle-like precipitates along the grain boundaries. Such precipitates typically lead to reduced shunt resistance. Crystallographic defects that lower the current collection and the final cell efficiency can also be identified. Understanding the influence of these defects is important for the development of a crystallization technology that results in a substantially better cell efficiency. The use of the improved material quality in an innovative cell and module technology have led to the world record module efficiency of 17%. This paper will illustrate one example of how an improved understanding of multicrystalline wafer quality can explain the variations in cell performance.
This paper, the third in a series covering cost of ownership (COO) studies for photovoltaics [1], examines the need for metallization of silicon-based solar cells and how it has evolved over the past few years. The technologies and techniques that are being developed for this part of cell manufacturing in the foreseeable future are also discussed. The paper will conclude with a COO case study using the DEK Solar PV3000 as an example.
One-step screen-printing processes are still the most widely-used technique for the front-side metallization of crystalline silicon solar cells in the PV industry. This is because of the knowledge, stability and speed of the process, and despite some big disadvantages exhibited by the resulting contacts. Therefore, the metal contacts of high-efficiency laboratory cells are usually produced via advanced two-step metallization processes, which allow the application of optimized contact structures. In a first step, a narrow metal layer is applied to form the contact to the silicon wafer. Several different techniques have been developed for this first stage. In the second step, the seed layer is reinforced electrochemically with a dense layer of a metal of high conductivity, usually by light-induced plating. The transfer of such techniques into industrial scale has been pursued intensively, and may enter solar cell production lines in the near future. However, the process can still be improved based on a better process understanding, in order to benefit from the full potential of the technology.
Standard solar cell technology nowadays offers a variety of measures - some linked, some not - to continuously improve conversion efficiency. The starting point for considering the different improvement steps is a kind of standard cell as produced on most current production lines. The main elements of this cell are diffused junction, aluminium back-surface field and screen-print metallization. This type of cell suffers losses from different sources like optics, recombination and resistance that can be considerably lowered to obtain higher cell efficiency. This paper will describe improvement steps on the standard type of multi-crystalline cell before addressing cell concepts that open further potential.
