Durable MWT PV modules made using silicone electrically conductive adhesive and an automated assembly line

Share on facebook
Facebook
Share on twitter
Twitter
Share on linkedin
LinkedIn
Share on reddit
Reddit
Share on email
Email

By Hongfeng Lin, Vice CTO and Director of the R&D Centre, Tianwei New Energy; Kaiyan Cao, Tianwei New Energy; Zhe Qui, Member of MWT Module Technology Team, Tianwei New Energy; Liyan Zhao, R&D Engineer, Tianwei New Energy, Chengdu, P.R.C.; Wei Long, Assistant Director of the R&D Centre and Pilot Line Manager, Tianwei New Energy; Xianzhi Chen, Research Fellow, Tianwei New Energy; Brian Chislea, Dow Corning Corporation; Guy Beaucarne, R&D Group Leader, Dow Corning Europe S.A.; Peng (Jason) Wei, Dow Corning China; Adriana Zambova, Dow Corning Corporation; Yanghai Yu, Product Development Chemist, Dow Corning China; Guo Yi, Silicone Sealant Development Group Leader, Dow Corning China; Kees Broek, Solar Energy Researcher, ECN; Ian Bennett, Researcher, ECN; Jan Bakker, CTO, Eurotron; Nico van Ommen, Process Engineer, Eurotron; Egbert Fredrikze, Equipment Engineer, Eurotron

Metal wrap-through (MWT) module technology is an attractive approach for increasing module efficiency. This paper shares the results of MWT module fabrication using a silicone electrically conductive adhesive (ECA), a conductive backsheet (CBS) with a thin organic layer surface finish, and an automated module assembly line. Very low cell-to-module (CTM) power losses are observed, leading to a multicrystalline Si module power of 266W and a full-area efficiency of 16.8%. The modules are very stable in damp-heat conditions and thermal cycling, demonstrating minimal degradation after 1.5 x IEC requirements in terms of damp heat and thermal cycling, and well below 2% degradation after 2 x IEC requirements. These MWT modules have received IEC 61215 and IEC 61730 certification.
